CM3024Z 12V24V 30A Solar Controller LCD Display Solar Charge Controller
CM3024Z 12V24V 30A Solar Controller LCD Display Solar Charge Controller
Sale
Sold out
Pre-order
Regular price
R 549.00
Regular price
Sale price
R 549.00
Unit price
per
Couldn't load pickup availability
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Description
• Product type: Others
• Compatibility: 12V/24V systems
• Material: Not specified
• Key feature: LCD display
• Color/Variant: Not specified
• Intended use: Everyday use
• Category: Consumer Electronics
parameter:1. Rated voltage: 12/24V lead-acid battery voltage2. Maximum charge and discharge current: 30A3. Solar panel input voltage range: maximum 18V-450W/36V-900W4. Load working time setting: 1-24 hours adjustable5. Charging mode: PWM6. Overvoltage protection: 17V/34V7. Fully disconnected: 13.7V/27.4V8. Undervoltage disconnect: 10.5V/21V9. Over-discharge recovery voltage: 12.2V/24.4V10. Wiring specifications: less than or equal to No. 7 AWG (16 square millimeters)11. Working environment temperature: -25-55 degrees CelsiusFeatures:1. Vivid LCD graphic symbols2. Automatic recognition of system voltage level3. Automatic temperature compensation4. Settable load working mode5. Battery undervoltage protection6. Overload, short circuit protection7. Simple key operation8. Intelligent PWM charging method9. Adjustable charge and discharge control parameters10. Accumulation of charge and discharge ampere hours11. Battery reverse discharge protection12. Battery reverse connection protection
• Compatibility: 12V/24V systems
• Material: Not specified
• Key feature: LCD display
• Color/Variant: Not specified
• Intended use: Everyday use
• Category: Consumer Electronics
parameter:1. Rated voltage: 12/24V lead-acid battery voltage2. Maximum charge and discharge current: 30A3. Solar panel input voltage range: maximum 18V-450W/36V-900W4. Load working time setting: 1-24 hours adjustable5. Charging mode: PWM6. Overvoltage protection: 17V/34V7. Fully disconnected: 13.7V/27.4V8. Undervoltage disconnect: 10.5V/21V9. Over-discharge recovery voltage: 12.2V/24.4V10. Wiring specifications: less than or equal to No. 7 AWG (16 square millimeters)11. Working environment temperature: -25-55 degrees CelsiusFeatures:1. Vivid LCD graphic symbols2. Automatic recognition of system voltage level3. Automatic temperature compensation4. Settable load working mode5. Battery undervoltage protection6. Overload, short circuit protection7. Simple key operation8. Intelligent PWM charging method9. Adjustable charge and discharge control parameters10. Accumulation of charge and discharge ampere hours11. Battery reverse discharge protection12. Battery reverse connection protection
